Details
| Model | EXD-C150H | EXD-C250H | EXD-C350H | EXD-C500H | EXD-C800H | EXD-C1000H | EXD-C1500H | EXD-C2000H |
|---|---|---|---|---|---|---|---|---|
| Voltage (V) | 220-240 | 220-240 | 220-240 | 220-240 | 220-240 | 220-240 | 220-240 | 220-240 |
| Input Power(W) | 40 | 100 | 120 | 150 | 200 | 350 | 750 | 800 |
| Fan Speed | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Running Current (A) | 0.2 | 0.5 | 0.6 | 0.7 | 1 | 1.6 | 3.5 | 3.8 |
| Airflow(m³/h) | 150 | 250 | 350 | 500 | 800 | 1000 | 1500 | 2000 |
| External Pressure (Pa) | 80 | 100 | 120 | 120 | 120 | 120 | 120 | 120 |
| Product Volume (mm) | 552*507*230 | 712*552*250 | 750*600*265 | 800*700*265 | 1000*809*342 | 1000*809*342 | 1143*809*342 | 1245*956*360 |
| Temperature Exchange Efficiency (%) (Heating) | 80% | 80% | 80% | 80% | 80% | 80% | 80% | 80% |
| Temperature Exchange Efficiency (%) (Cooling) | 70% | 70% | 70% | 70% | 70% | 70% | 70% | 70% |
| Noise dB(A) | 30 | 35 | 37 | 40 | 42 | 42 | 48 | 48 |
| Weight (kg) | 23 | 25 | 30 | 35 | 67 | 75 | 130 | 150 |
Efficient performance and minimal noise are core to our design philosophy.Heat Recovery Ventilator offers low SFP and optimal duct system pressure. Provides energy-efficient fan operations and low operational costs.
Features 30 mm insulated casings and 50 mm insulated hatches for sound reduction, ensuring a quiet environment. Utilizes heat exchangers with efficient heat recovery and low pressure drops.
Employs high-efficiency EC fans with reduced energy use.Guarantees superior indoor air quality with effective filtration.
Super Quiet
With Exinda’s Heat Recovery Ventilator upgrared noise reduction technology, and professional air channel design and high quality components to make sure silence operation.
Quality assurance
Exinda’s Heat Recovery Ventilator excels in product testing and performance with our owner Enthalpy Difference Laboratory and Noise Chamber Advantage.
Our rigorous testing ensures product reliability and consistency, while our Noise Chamber ensures operation at whisper-quiet levels. Exinda’s units promise swift and reliable operation.
Rely on Exinda’s Heat Recovery Ventilator for high-performing, low-noise, and dependable solutions.
Fresh Air Filtration System
As a standard, Exinda’s Heat Recovery Ventilator units are equipped with the filtration system, based on a set of G4 pre-filters installed on the air inlet and outlet.
Additionally, in order to obtain high air quality in a room, a whole range of high efficiency filters is available, starting from F5 up to H13 filter.
Choice of the filtration class makes it possible to adapt functionality of the heat recovery unit to the customer needs.
Intelligent Control System
Exinda’s Heat Recovery Ventilator intelligent control system, it can effectively improve indoor air quality, increase indoor oxygen content, and at the same time greatly reduce the power load of indoor air conditioning equipment, with high efficiency and energy saving.
High efficiency and energy saving
In the pursuit of keeping our houes insulated and energy efficient, Exinda’s Heat Recovery Ventilator remove molds, bacteria, fungus, VOCs, allergens, carbon dioxide and carbon monoxide in a sealed indoor environment.
Exinda’s Heat Recovery Ventilator remove the indoor polluted air with ease and provide a constant supply of clean filtered air, allowing you and your family to live in an healthy indoor environment.
The heat from the exhaust air is transferred to the incoming air via a heat exchanger. The heat recovery efficiency is up to 85%.
The Exinda’s Heat Recovery Ventilator saves energy up to 60% compared to natural ventilation.
Exinda’s Heat Recovery Ventilator units are equipped with high performance enthalpy heat exchanger that enables higher percentage values of temperature recovery, both in summer and winter.
Cross-flow exchanger provides also moisture recovery between air supplied to the room and exhaust air, supporting thereby further increase of occupants comfort. The heat exchange materials are mildew resistance and fire retardance.
- Easy installtion: The slim design ensures straightforward installation in ceiling spaces and easy transport through doorways and hallways.
- Wireless Access Control System: Manage Breeze units using a device app, eliminating the need for direct unit access and simplifying installation.
- Energy-Efficient with Low Operational Costs: Equipped with counterflow heat exchangers, Exinda Breeze units ensure optimal energy efficiency and minimized operational expenses.
- Space-Saving Breeze Units: Given the high demand for floorspace, our ceiling units offer an economical and compact solution for optimal indoor comfort. Suitable for 300 to 1,500 square meters, these units are easily selectable on our site and come in various sizes.
Easy Installation
Compact design achieves high air volume, with specialized access doors for system management and fan upkeep. With its ceiling-mounted configuration and side ports, it occupies very little space.
Easy Maintenance
Simplified Filter Maintenance in Exinda Breeze Series
Side accessibility for filter servicing.
Recommended bi-annual filter replacement.
Built-in filter monitoring alerts for timely changes, preventing elevated operational costs.
Optional pre-filters available for enhanced filtration or secondary filter protection.
Pre-installed filter rails enable easy panel filter accessory integration.
